F-Option for Chemical Resistance

Fluorocarbon sealant for our Outdoor Ultrasonic Sensors


F-Option for Chemical Resistance

F-Option

Lead time may vary for larger orders
For 1 MB7XXX Sensor
$40.00
For 5 MB7XXX Sensor
$200.00
For 10 MB7XXX Sensor
$400.00
For 50 MB7XXX Sensor
$1208.00
For 100 MB7XXX Sensor
$2416.00
For pricing of orders with more than 100 units, please complete our Quote Request Form.
(For all online orders, ensure that the quantity of WR sensors ordered matches the quantity of F-Option)

(If you wish to order quantities that do not match, contact sales)

For larger quantities, please contact MaxBotix Inc. for pricing.

Product Description



In addition to the standard MaxSonar‑WR, MaxBotix Inc. has developed the F-Option for additional protection necessary in a few hazardous chemical environments. Extremely corrosive gases or liquids can degrade or compromise the operation of the sensing unit. As a result, we offer a more chemically inert seal which allows our sensors to operate in all but the harshest of chemical environments. In addition to the chemical resistance the sensor has improved performance in wet or dust environments.

Please Note: Our sensors are designed for operation in normal atmosphere (air).  Please be aware that the speed of sound and atmospheric attenuation may change as a result of the transmission properties of different chemical/air mediums.  Users are strongly encouraged to characterize and test the operation of the sensor in the new medium to verify operation, and properly scale the outputted range information.

F-Option

The exposed materials of a properly mounted MaxSonar‑WR sensor with the F-Option added are: Aluminum (oxidized surface), PVC, & Fluorosilicone (with an additional back up FEP Teflon® seal).

Standard Weather Resistant Models

The exposed materials of a properly mounted MaxSonar‑WR standard sensor are: Aluminum (oxidized surface), PVC, & silicone rubber (VMQ).

Compatibility

The F‑Option is compatible with the following sensor lines:

  • 4-20HR‑MaxSonar‑WR
  • 4-20SC‑MaxSonar‑WR
  • HRXL‑MaxSonar‑WR
  • HRXL‑MaxSonar‑WRS
  • SCXL‑MaxSonar‑WR
  • SCXL‑MaxSonar‑WRS
  • I2CXL‑MaxSonar‑WR
  • XL‑MaxSonar‑WR

Component Overview

  • RoHS Compliant
  • Fluorosilicone Sealant (with an additional back up FEP Teflon® seal)
